Projects

— Expand All | All Collapse —

Correctional Institutions Correctional Institutions

Lobo has worked on approximately 22 adult correctional facilities, 7 youth correctional facilities, and 1 immigration holding centre. Lobo has also developed the Security System Standards/Guidelines for the Ministry of Community Safety and Correctional Services (MCSCS) in Ontario and the Ministry of Children and Youth Services (MCYS) in Ontario. As such, Lobo has a very strong understanding of the operational and security requirements of correctional facilities.


Click to view our projects

South West Detention Centre — Winsor, Ontario

South West Detention Centre

Budget: $120,000,000 (Construction), $6,000,000 (Security)

Project Description: Design and construction of a new 315 bed , 200,000 sq ft, maximum security correctional facility. The facility accommodates both male and female offenders. This state-of-the-art detention centre includes all support spaces including kitchen, infirmary, receiving/stores, laundry, full gymnasium, administrative and staff spaces.

The security consists of multiple security systems integrated into a single touchscreen control and monitoring system. All security systems utilized the latest technology. The Integrated Security System following systems: Detention Door Control, IP Video Surveillance (450+ cameras), Video Analytic, Access Control, Intercom, Public Address, Passive Duress Alarm, Personal Duress Alarm, Watchtour, Cell Call, and Perimeter Intrusion Detection. The touchscreen control system also integrated the following building systems on the HMI: fire alarm, water control, lighting, power control, elevator control, and HVAC. The security systems also consisted of a video visitation system to allow inmates to communicate with visitors electronically to eliminate unnecessary movement throughout the facility. Mobile devices were incorporated to display inmate information for dispensing medicines and verifying inmate identification.

Numerous redundancies (system level and network level) were built into the design to ensure failure of any component would have minimal downtime, if any.

Role/Responsibility: Lobo was the Security and IT consultants responsible to design the Integrated Security System and IT System. Lobo also performed full contract administration and commissioning services.

Central North Correctional Centre — Penetanguishene, Ontario

Central North Correctional Centre

Budget: $2,000,000 (Security)

Project Description: Project Description: Major security upgrades for the 1,200 bed maximum security correctional facility. The upgrades included a new touchscreen controlled integrated security system based on the new MCSCS Security Standards. A new HMI was incorporated to enhance operator monitoring and control efficiency and minimize response time to security related incidents. The existing PLCs were replaced with new PLCs with built-in redundancies. The video surveillance system was upgraded to a new IP based system. Additional IP cameras were added to the system for a total of 250+ cameras on the new system. A roof detection system was incorporated, consisting of video motion detection cameras and non-cool thermal cameras and enhanced video analytics.

The security systems were upgraded while the facility was fully operational. A well thought-out phasing plan was incorporated to ensure the downtime was minimal during the transition period from the existing systems to the new systems.

Role/Responsibility: Lobo was the lead security consultants/prime consultant responsible to design the Integrated Security System. Lobo produced the construction documents, including drawings and specifications. Lobo also performed contract admin services, including construction review and commissioning and testing.

Elgin Middlesex Detention Centre — London, Ontario

Elgin Middlesex Detention Centre

Budget: $3,200,000 (Construction), $2,500,000 (Security)

Project Description: Renovations to the front lobby and control rooms and major security upgrades for the existing 450 bed maximum security correctional facility. The upgrades included a new touchscreen controlled integrated security system based on the new MCSCS Security Standards to replace the existing hardwired pushbutton panel. A new HMI was incorporated to enhance operator monitoring and control efficiency and minimize response time to security related incidents. A new PLC system with built-in redundancies was incorporated to control and monitor doors and alarm points. The video surveillance system was upgraded to a new IP based system. Additional IP cameras were added throughout the facility to achieve 100% coverage for a total of 350+ IP cameras on the new system. A new detention grade intercom system and inmate visitation system was incorporated. All security systems were integrated on the touchscreen control system.

The Central Control Room and Front Control Room were renovated to ensure monitoring and control functionality was as per ergonomic guidelines.

The security systems were upgraded while the facility was fully operational. A well thought-out phasing plan was incorporated to ensure the downtime was minimal during the transition period from the existing systems to the new systems.

Roles/Responsibility: Lobo was the lead security consultants/prime consultant responsible to design the Integrated Security System. Lobo produced the construction documents, including drawings and specifications. Lobo also performed contract admin services, including construction review and commissioning and testing.

Ottawa Carleton Detention Centre — Ottawa, Ontario

Ottawa Carleton Detention Centre

Budget: $23,000,000 (Construction), $2,700,000 (Security)

Project Description: A major addition to the existing detention centre which included a maximum security “pod style” unit and support areas. The integrated security system for this maximum security facility consists of 21 sub-systems, such as: Computer Controlled Door Locking and Alarm Reporting Systems, CCTV Systems, Duress Alarm Systems (Active and Passive), Nurse Call System, Perimeter Security Systems, Communications Systems and Fire Alarm System.

Role/Responsibility: Lobo was the design consultants for the Integrated Security & Communications Systems. Services included: Engineering Design Drawings, Engineering Specifications, Construction Review, Commissioning & Testing, including warranty periods.

Ministry of Community Safety and Correctional Services, Ontario

Ministry of Community Safety and Correctional Services

Electronic Integrated Security System Standards

Project Description: Development of the Electronic Integrated Security System Standards for all MCSCS detention centres and jails in Ontario. The Standards detailed the graphical user interface (GUI) and exact sequence of events and operations to control and monitor all alarms. The Standards also detailed the technology, interfaces, and operational requirements for each security system. The integrated security system consists of the following sub-systems: Security Monitoring and Control System, Video Surveillance System, Door Control System, Access Control System, Intercom System, Cell Call System, Public Address System, Passive Duress Alarm System, Active Duress Alarm System, Watchtour System, and Perimeter Security System.

The security standards were to overcome all security vulnerabilities and improve operator control and monitoring efficiency. The Standards will be implemented in all MCSCS correctional facilities in Ontario.

Role/Responsibility: Lobo was the security consultants/prime consultant responsible to develop the Integrated Security System Standards for MCSCS. This included visiting various MCSCS facilities throughout the province and interviewing various operators and management. Lobo worked very closely with MCSCS representatives to develop the MCSCS security operational and functional requirements which was detailed throughout the Standards.

Full List of Correctional Facilities (30)

Full List of Correctional Facilities

Adult Facilities Facilities (22):

  • Algoma Treatment and Remand Centre, Sault Ste Marie, Ontario
  • Brantford Jail, Brantford, Ontario
  • Central East Detention Centre, Lindsay, Ontario
  • Central North Detention Centre, Penetanguishene, Ontario
  • Elgin Middlesex Detention Centre, London, Ontario
  • Hamilton Wentworth Detention Centre, Hamilton, Ontario
  • Maplehurst Correctional Centre, Milton, Ontario
  • Millhaven Correctional Centre, Kingston, Ontario
  • Niagara Detention Centre, Thorold, Ontario
  • North Bay Jail, North Bay, Ontario
  • Ottawa Carleton Detention Centre, Ottawa, Ontario
  • Quinte Detention Centre, Napanee, Ontario
  • Rankin Inlet Correctional Healing Facility, Nunavut
  • Sarnia Jail, Sarnia, Ontario
  • South West Detention Centre, Windsor, Ontario
  • St. Lawrence Valley Correctional Centre, Brockville, Ontario
  • Toronto East Detention Centre, Toronto, Ontario
  • Toronto South Detention Centre, Toronto, Ontario
  • Toronto West Detention Centre, Toronto, Ontario
  • Vanier Centre for Women, Milton, Ontario
  • Walkerton Jail, Walkerton, Ontario
  • Windsor Jail, Windsor, Ontario

Youth Correctional Facilities (7):

  • Brookside Youth Detention Centre, Cobourg, Ontario
  • Fort Francis Youth Detention Centre, Fort Francis, Ontario
  • Roy McMurtry Youth Centre, Brampton, Ontario
  • Sprucedale Youth Detention Centre, Simcoe, Ontario
  • Sault Ste Marie Youth Detention Centre, Sault Ste Marie, Ontario
  • Thunder Bay Youth Detention Centre, Thunder Bay, Ontario
  • William E Hays Centre, Ottawa, Ontario

Holding Facilities (1):

  • Toronto Immigration Holding Centre, Toronto, Ontario

Courthouse FacilitiesCourthouse Facilities

Lobo has worked on over 45 courthouses. Lobo has also developed the Security System Standards/Guidelines for the Ministry of the Attorney General (MAG) for all courthouses in Ontario and the Security System Guidelines for Alberta Infrastructure for all courthouses in Alberta. As such, Lobo has a very strong understanding of the operational and security requirements of courthouse facilities.


Click to view our projects

Durham Consolidated Courthouse — Oshawa, Ontario

Durham Consolidated Courthouse

Budget: $250,000,000

Project Description: Design and construction of a new six storey, 400,000 sqft courthouse, consisting of 33 courtrooms, associated support space and prisoner holding facilities. The courthouse was to be a model for future consolidated courthouses in Ontario.

The security system incorporated a touchscreen control system to monitor and control all security sub-systems. All cells and circulation doors within the prisoner holding area were remotely controlled from the touchscreen control system. The security system provided for a fully integrated system, allowing for ease of monitoring and superior control capabilities. The security consisted of the following systems: Detention Door Control, Video Surveillance, Access Control, Intercom, Audio Surveillance, and Duress Alarm. All security systems were integrated on the touchscreen control system.

Role/Responsibility: Lobo was the Security and IT design consultants. Lobo was responsible for the design of the Integrated Security System and the IT/Voice-Data Structured Cabling Infrastructure System, preparing the engineering specifications and drawings, sketches, and security door details.

Lobo also provided construction admin services, reviewing shop drawings, providing construction reviews, and commissioning and performance testing.

Thunder Bay Consolidated Courthouse — Thunder Bay, Ontario

Thunder Bay Consolidated Courthouse

Budget: $150,000,000

Project Description: Design and construction of a new six storey, 255,000 sqft courthouse, consisting of 18 courtrooms, associated support space and prisoner holding facilities.

The security system incorporated a touchscreen control system to monitor and control all security sub-systems. All cells and circulation doors within the prisoner holding area were remotely controlled from the touchscreen control system. The security system provided for a fully integrated system, allowing for ease of monitoring and superior control capabilities. The security consisted of the following systems: Detention Door Control, IP Video Surveillance, Access Control, Intercom, Audio Surveillance, and Duress Alarm. All security systems were integrated on the touchscreen control system.

Roles/Responsibility:Lobo was the Security and IT design consultants. Lobo was responsible for the design of the Integrated Security System and the IT/Voice-Data Structured Cabling Infrastructure System, preparing the engineering specifications and drawings, sketches, and security door details. Lobo also provided construction admin services, reviewing shop drawings, providing construction reviews, and commissioning and performance testing.

Grenville and William Davis Courthouse — Brampton, Ontario

Grenville and William Davis Courthouse

Budget: $1,000,000 (Security)

Project Description: Upgrades to the existing six storey, 400,000 sqft courthouse, consisting of upgrading the Integrated Security System in the detention area to provide the latest security technology. The system included the introduction of a touchscreen controlled system to remotely control all accused cell and circulation doors from a single central secure control room. The new system interfaced all security systems, including the CCTV System, Detention Door Control System, Cell Request System, and Intercom System, into a single monitoring system. The new security system was to be a model for all future courthouses in Ontario.

Roles/Responsibility: Lobo was the security design/prime consultants. Lobo was responsible for the design of the Integrated Security System, preparing the engineering specifications and drawings as well as the contract documents. Lobo was responsible to coordinate all work by sub-consultants, including the detention hardware.

Lobo extended services to provide construction admin services, reviewing shop drawings, providing construction reviews, and commissioning and performance testing.

Toronto Courthouse — Toronto, Ontario

Toronto Courthouse

Budget: $5,000,000

Project Description: Major upgrades to the existing eight storey, 425,000 sqft historic courthouse located in the heart of Toronto. The security upgrades consisted of upgrading the Access Control System and Video Surveillance System throughout the courthouse to provide the latest security technology. The existing Access Control System was replaced with an enterprise level system along with smart card readers. Additional card readers were added to the facility based on MAG Standards. The existing analog video surveillance system was replaced with a new IP based system. Additional IP cameras were added throughout the facility to provide coverage based on MAG Standards.

As the courthouse is a designated historic building, in-depth coordination was employed with the historic consultant to ensure the security devices added did not detract from the historic nature of the building.

The security systems were upgraded while the facility was fully operational. A well thought-out phasing plan was incorporated to ensure the downtime was minimal during the transition period from the existing systems to the new systems.

Roles/Responsibility: Lobo was the security design consultants. Lobo was responsible for the design of the Security Systems, preparing the engineering specifications and drawings as well as the contract documents. Lobo extended services to provide construction admin services, reviewing shop drawings, providing construction reviews, and commissioning and performance testing.

Ministry of the Attorney General — Ontario

Ministry of the Attorney General

Province of Ontario Courthouse Security Technology Guidelines

Project Description: Development of the new security technology guidelines for the Ministry of the Attorney General. The guidelines were to incorporate the latest security technology suitable in a courthouse application. The document described each system, the associated technology, system functional and performance requirements, system composition, system interfaces, and infrastructure. The document was to act as a security guideline for all new courthouse facilities and existing courthouse facilities in Ontario.

The security systems within the Guidelines consisted of: Access Control and Alarm Monitoring, Video Surveillance, Digital Video Recording, Duress Alarm, Parking Alarm, Personal Alarm, Intrusion Alarm, Audio Surveillance, Door Intercom, Jury Intercom, Detention Door Control, Metal Detection, and X-Ray Screening.

Roles/Responsibility: Lobo was responsible to develop the Security Technology Guidelines.

Full List of Courthouses (45)

Full List of Courthouses

  • 2201 Finch Ave Courthouse, Toronto, Ontario
  • 330 University Courthouse, Toronto, Ontario
  • 393 University Courthouse, Toronto, Ontario
  • Barrie Courthouse, Barrie, Ontario
  • Brantford Courthouses, Brantford, Ontario
  • Brockville Courthouse, Brockville, Ontario
  • Burlington Courthouse, Burlington, Ontario
  • Chatham Courthouse, Chatham, Ontario
  • Cobourg Courthouse, Cobourg, Ontario
  • Cornwall Courthouse, Cornwall, Ontario
  • Dryden Courthouse, Dryden, Ontario
  • Dufferin County Courthouse, Orangeville, Ontario
  • Durham Consolidated Courthouse, Oshawa, Ontario
  • Fort Frances Courthouse, Fort Frances, Ontario
  • Frontenac County Courthouse, Kingston, Ontario
  • Grenville and William Davis Courthouse, Brampton, Ontario
  • Guelph Consolidated Courthouse, Ontario
  • John Sopinka Courthouse, Hamilton, Ontario
  • Kitchener Courthouse, Kitchener, Ontario
  • Lindsay Courthouse, Lindsay, Ontario
  • London Courthouse, London, Ontario
  • Midland Courthouse, Midland, Ontario
  • Milton Courthouse, Milton, Ontario
  • Mississauga POA Courthouse, Mississauga, Ontario
  • Newmarket Courthouse, Newmarket, Ontario
  • Norfolk County Courthouse, Simcoe, Ontario
  • North Bay Courthouse, North Bay, Ontario
  • Oakville Courthouse, Oakville, Ontario
  • Old City Hall Courthouse, Toronto, Ontario
  • Ossgoode Hall Courthouse, Toronto, Ontario
  • Owen Sound Courthouse, Owen Sound, Ontario
  • Parry Sound Courthouse, Parry Sound, Ontario
  • Pembroke Courthouse, Pembroke, Ontario
  • Peterborough Courthouse, Peterborough, Ontario
  • Quinte Consolidated Courthouse, Belleville, Ontario
  • Sarnia Courthouse, Sarnia, Ontario
  • Simcoe Courthouse, Simcoe, Ontario
  • St. Catherines Courthouse, St. Catherines, Ontario
  • St. Lawrence Market POA Courthouse, Toronto, Ontario
  • Sioux Lookout Courthouse, Sioux Lookout, Ontario
  • Thunder Bay Consolidated Courthouse, Thunder Bay, Ontario
  • Thunder Bay Courthouse, Thunder Bay, Ontario
  • Toronto Courthouse, Toronto, Ontario
  • Welland Courthouse, Welland, Ontario
  • Wellington County Courthouse, Guelph, Ontario
  • Windsor Courthouses, Windsor, Ontario
  • Woodstock Courthouse, Woodstock, Ontario

Police Facilities Police Facilities

Lobo has worked on over 59 police facilities throughout Canada. These facilities include police headquarters, detachments, forensic identification units, and call centres. Lobo was also involved in the development of the Ontario Provincial Police (OPP) Accommodation Guidelines for all OPP detachments in Ontario. As such, Lobo has a very strong understanding of the operational and security requirements of various police facilities.


Click to view our projects

Ontario Provincial Police (OPP) Modernization

Ontario Provincial Police Modernization

Budget: $150,000,000

Project Description: Design and construction of 18 OPP facilities, including detachments, Forensic Investigative Units (FIU), Police Command Centre (PCC), and Regional Command Centres (RCC). The facilities were built at the same time.

The Forensic Investigative Units were located in: Mount Forest, South Porcupine, Peterborough, Long Sault, Chatham-Kent, Kenora, Smiths Falls, and North Bay.

The Detachments were located in: Walkerton, Kapuskasing, Iroquois Falls, Armstrong, Nipigon, Burk’s Falls, and Dryden.

The Regional Command Centre was located in: Smiths Falls, North Bay, and Orillia.

Role/Responsibility: Lobo was responsible to develop the Security System and Voice-Data System requirements for each facility. Services included: System layouts, output specifications, and room data sheets for each facility.

Saskatoon Police Headquarters — Saskatoon, Saskatchewan

Saskatoon Police Headquarters

Budget: $100,000,000

Project Description: Design and construction of a new five-storey, 350,000 sq ft police headquarters. Facility included detention area, public spaces, office spaces, and various police departmental spaces. The detention area contained 57 cells and interview rooms.

The security systems consisted of a touchscreen controlled detention door control system, IP video surveillance system, access control system, duress alarm system, intercom system, and audio monitoring system.

Roles/Responsibility: Lobo was responsible to develop the Security System and Voice-Data System requirements for the facility. Services included: System layouts, output specifications, and room data sheets.

Saint John Police Headquarters — Saint John, New Brunswick

Saint John Police Headquarters

Budget: $21,000,000

Project Description: Design and construction of new multi level, 107,000 sqft police headquarters. Facility included detention area, public spaces, office spaces, and various police departmental spaces. The detention area contained 22 cells and interview rooms. The police headquarters was connected to the adjacent courthouse to allow the courthouse to share the holding area.

The security system consisted of an Access Control and Alarm Monitoring System, an IP Video Surveillance System and a Video and Audio Monitoring System specifically designed to interview rooms.

Roles/Responsibility: Lobo was responsible to design the Security Systems for the facility. Services included: System layouts, riser diagrams, door details, engineering specifications, and contract admin services.

Waterloo Regional Police Buildings — Waterloo, Ontario

Waterloo Regional Police Buildings

Budget: $13,000,000

Project Description: Design and construction of a new two-storey 40,000 sqft police facility with associated functional spaces, such as Forensic, Administration, Technical Crime, Homicide, Major Crimes, Fraud, and Support Areas.

Design and renovation of the WRPS Comm Centre with associated functional spaces.

Roles/Responsibility: Lobo designed the Voice-Data Cabling System. Services included: Engineering Design Drawings, Engineering Specifications, Construction Review, Commissioning & Testing.

OPP Accommodations Guidelines for Detachments

OPP Accommodations Guidelines for Detachments

Ontario Provincial Police (OPP)

Project Description: Development and update of the OPP Accommodation Guidelines for Detachments. The document was to be used as a guide for any new and existing OPP detachment throughout Ontario.

The document outlined specific design requirements, device locations, and specific manufacturers and models that are acceptable related to the Security and IT/Voice-Data Systems. The document also provided functional overviews of the systems.

Roles/Responsibilities: Lobo was responsible to develop the Security System and Voice-Data System requirements for the Accommodation Guidelines in close discussion with the OPP.

Full List of Police Facilities (59)

Full List of Police Facilities

  • Aylmer Police College, Aylmer, Ontario
  • Cambridge CACC 911 Call Centre, Cambridge, Ontario
  • Lindsay 911 Dispatch Centre, Lindsay, Ontario
  • Niagara Regional Police Headquarters, Niagara, Ontario
  • Ontario Provincial Police (OPP) Accommodations Guidelines for Detachments
  • Ontario Provincial Police (OPP) Eastern Region (30 facilities)
  • Ontario Provincial Police (OPP) Kawartha Lakes Detachment
  • Ontario Provincial Police (OPP) Modernization (18 facilities)
  • Ontario Provincial Police (OPP) PanAm ISU office, Brampton, Ontario
  • Saint John Police Headquarters, Saint John, New Brunswick
  • Saskatoon Police Headquarters, Saskatoon, Saskatchewan
  • Waterloo Regional Police Buildings, Waterloo, Ontario
  • Whitby OPP Detachment, Whitby, Ontario

Healthcare Facilities Healthcare Facilities

Lobo has worked on 7 healthcare facilities including hospitals, mental health centres and long term care facilities. Lobo has put forth solutions that provide effective monitoring of multiple buildings to minimize response time and create a safe environment for patients, staff and visitors.




Click to view our projects

Centre for Addiction and Mental Health — Toronto, Ontario

Centre for Addiction and Mental Health

Budget: $180,000,000

Project Description: Planning/schematic design of three new buildings totalling 450,000 sq ft to expand and redevelop the existing Queen St complex. The redevelopment included new streets, sidewalks, and three new CAMH facilities, consisting of the seven-storey Gateway Building, the six-storey Intergenerational Wellness Centre, and the eight-storey Utilities and Parking Building. Buildings included healthcare and associated functional spaces.

Roles/Responsibility: Lobo developed the Security requirements of the Planning/Schematic Design Documents. Services included the development of security output specifications and security design guidelines.

Ontario Shores Mental Health Centre — Whitby, Ontario

Ontario Shores Mental Health Centre

Budget: $1,000,000

Project Description: The scope of the project is to provide a scalable, security management system suitable for large institutions that will provide the capability of seamlessly integrating numerous applications including card access control and alarm monitoring, badging and digital imaging, e-mail, paging, CCTV, elevator control, escort management and asset management. The intent is to phase-in a complete card access control system for the facility encompassing approximately 750 of the 1500 security door locations. The initial phase of the installation is to provide proximity type card reader access control at 180 door locations.

The security systems were upgraded while the facility was fully operational. A well thought-out phasing plan was incorporated to ensure the downtime was minimal during the installation of the new systems.

Roles/Responsibility: Lobo was retained by the Ministry of Health and the Ontario Realty Corporation to provide the required security system engineering/design, contract documents, contract administration and commissioning/testing of the system.

Penetanguishene Mental Health Centre — Penetanguishene, Ontario

Penetanguishene Mental Health Centre

Budget: $500,000

Project Description: Incorporation of an electronic card access control system for the Penetanguishene Mental Health Centre complex. The complex consists of 5 multi-storey buildings with administrative, patient, and maintenance functions.

The security systems were upgraded while the facility was fully operational. A well thought-out phasing plan was incorporated to ensure the downtime was minimal during the transition period from the existing systems to the new systems.

Roles/Responsibility: Lobo was the prime consultants to develop the security requirements and design of the electronic access control system. Services included the development of contract documents, tendering, contract admin, commissioning & performance testing.

Princess Margaret Hospital – Cancer Care — Toronto, Ontario

Princess Margaret Hospital Cancer Care

Budget: unable to disclose

Project Description: Security audit of Cancer Care Ontario facilities part of Princess Margaret Hospital. Security audit included the Video Surveillance, Access Control, and Intercom. The security audit assessed all existing security systems and devices and the associated technologies. Based on the current security concerns and needs of the facility, recommendations were produced to overcome all security concerns and vulnerabilities and to bring the security to the latest technology and best practices.

Roles/Responsibility: Lobo was responsible to perform the security assessment. Lobo was also responsible to produce the security audit report and preparation of the associated security drawings.

Tall Pines Long Term Care Facility

Tall Pines Long Term Care Facility

Budget: $8,000,000

Project Description: Design and construction of a new three-storey, 162 bed long-term care facility with associated functional spaces.

The security systems consisted of an access control system, video surveillance system, intercom system, nurse call system, and patient wandering system.

Roles/Responsibility: Lobo was the Integrated Security System consultants. Services included: Engineering Design Drawings, Engineering Specifications, Construction Review, Commissioning & Testing.

Full List of Healthcare Facilities (7)

Full List of Healthcare Facilities

  • Centre for Addiction and Mental Health – Queen St, Toronto, Ontario
  • Forensic Mental Health Centre – Oak Ridge Facility, Penetanguishene, Ontario
  • Malton Village Long Term Care Facility, Mississauga, Ontario
  • Ontario Shores Mental Health Centre, Whitby, Ontario
  • Penetanguishene Mental Health Centre, Penetanguishene, Ontario
  • Princess Margaret Hospital – Cancer Care Ontario, Toronto, Ontario
  • Tall Pines Long Term Card Facility, Brampton, Ontario

Educational Facilities Educational Facilities

Lobo has worked on 11 educational facilities, including numerous campuses. Lobo's educational experience includes both international and Canadian projects. These projects have enabled Lobo to put forth solutions that utilize deterrent concepts to prevent undesired activity from occurring. This fosters a safe environment for students, staff and visitors.



Click to view our projects

Centennial College - Scarborough, Ontario

Centennial College

Budget: unable to disclose

Project Description: Security audit of all Centennial College campuses (seven campuses). Security audit included the Video Surveillance, Access Control, Intercom, Personal Safety (Duress), and Emergency Phone Systems. The security audit assessed all existing security systems and devices and the associated technologies. Based on the current security concerns and needs of the college, recommendations were produced to overcome all security concerns and vulnerabilities and to bring the security to the latest technology and best practices.

A new IP based video surveillance system is being incorporated to replace the existing analog system for all campuses. All cameras at all campuses will be monitored from a central location. This is a multi year, multi phase project.

Roles/Responsibility: Lobo was responsible to perform the security assessment. Lobo was also responsible to produced the security audit report and the associated security drawings.
A new IP based video surveillance system is being incorporated to replace the existing analog system for all campuses. All cameras at all campuses will be monitored from a central location. This is a multi year, multi phase project.

York University – Schulich School of Business - Toronto, Ontario

York University

Budget: $155,000,000

Project Description: Design and construction of the new Schulich buildings that include variety of teaching/academic spaces, offices and related support functions. The buildings included:
  • School of Business: 22,720m2.
  • Executive Learning Centre: 7,600m2.
  • Parking Structure #3 to accommodate 1,426 parking stalls.
The security systems included an extensive access control system, video surveillance system, duress alarm system, intercom system, and parking duress system. The systems were designed with the ability to reconstruct a security related incident to determine when an individual entered the facility to the point they left the facility.

Roles/Responsibility: Lobo was the design consultants for the Integrated Security & Communications Systems consisting of: Card Access Systems, CCTV Surveillance& Digital Recording Systems and Emergency Communications Systems. Services included: Engineering Design Drawings, Engineering Specifications, Construction Review, Commissioning & Testing.

Kuwait University - Kuwait

Kuwait University

Budget: $4,000,000,000 (Construction)

Project Description: Master Plan for new 30,000 student campus and associated academic and campus support facilities. Colleges include: Engineering, Science, Business Administration, Arts, Law, Education, Social Sciences, Allied Health Sciences, Dentistry, Medicine, and Pharmacy. Campus also includes 600-bed research hospital, medical research facilities, and parking facilities to accommodate 35,000 vehicles. The underground parking facility was required to serve as a bomb shelter as well, with the appropriate facilities.

Roles/Responsibility: Lobo developed the Security section of the Master Plan. Services included threat, risk, and vulnerability assessments, security concepts such as Crime Prevention Through Environmental Design (CPTED), and the development of security zones, security systems and security design guidelines.

Sir James Whitney School for the Deaf - Belleville, Ontario

Sir James Whitney

Budget: $500,000

Project Description: Security upgrades to the historic Provincial school for the deaf. Security upgrades were incorporated throughout the campus consisting of a variety of buildings, including Residences, Classroom buildings, Gymnasium, Administration, and support services. Security systems included Access Control, IP based Video Surveillance, and Intercom Systems.

As the students of the school were deaf, special considerations were made to ensure the security devices accommodated this disability.

Roles/Responsibility: Lobo was responsible to develop the Security requirements for the facility. Lobo was also responsible for the Security System design, preparing the security drawings for tender. Lobo also performed full contract administration and commissioning services.

University of Toronto - Wallberg and Pratt Building - Toronto, Ontario

University of Toronto

Budget: unable to disclose

Project Description: Incorporation of a new Access Control System for the existing Wallberg building and Pratt building. The new system is to enhance the security of the buildings to be in line with UofT`s overall security vision. The system is to connect to UofT's overall security system for monitoring, control, and database management.

Roles/Responsibility: Lobo was the prime security consultant. Lobo's responsibilities include developing the security concept for the buildings, coordinating the security and hardware with UofT representatives, preparing the engineering drawings and specifications, contract administration, project management and commissioning.

Full List of Educational Facilities (11)

Full List of Educational Facilities

  • Centennial College, Scarborough, Ontario
  • Centre Jules Leger School for the Deaf, Ottawa, Ontario
  • EC Drury School for the Deaf, Milton, Ontario
  • Fenelon Falls Secondary School, Lindsay, Ontario
  • Kuwait University, Kuwait
  • Lindsay Collegiate & VI Secondary School, Lindsay, Ontario
  • Roberts/Amethyst School for the Deaf and Blind, London, Ontario
  • Sir James Whitney School for the Deaf, Belleville, Ontario
  • University of Toronto Wallberg and Pratt Building, Toronto, Ontario
  • W. Ross Macdonald School for the Deaf and Blind, Brantford, Ontario
  • York University – Schulich School of Business, Toronto, Ontario

Residential / Commercial Facilities Residential & Commercial Facilities

Lobo has worked on over 27 residential/commercial facilities. These include office buildings, condominiums, retail, shopping mall, laboratories, museums, and parking facilities. These facilities had varying levels of security and Lobo was able to put forth design solutions to meet the specific security requirements of each facility.



Click to view our projects

World on Yonge Complex — Toronto, Ontario

World on Yonge Complex

Budget: unable to disclose

Project Description: Design and construction of a new condominium complex which consists of five towers. The towers consist of condominium residences, hotel, retail, offices, shopping mall and large underground parking structure.

Security systems include IP Video Surveillance (400+ IP cameras), Access Control, Intercom, Duress Alarm, Visitor Entry, etc.

Roles/Responsibility: Lobo developed the Security requirements of the facility. Lobo was responsible for the design of the Security System, including the preparation of system layouts, riser diagrams, door details, and engineering specifications .They were also responsible for contract admin services, including construction reviews, resolving construction issues, performance testing and commissioning.

77/99 Harbour St Condominium Complex — Toronto, Ontario

77/99 Harbour St Condominium Complex

Budget: unable to disclose

Project Description: Security audit of the Toronto harbour front condominium complex. The complex consisted of two residential towers and a multilevel parking facility. Security audit included the Video Surveillance, Access Control, Intercom, and Parking Duress. The security audit assessed all existing security systems and devices and the associated technologies. Based on the current security concerns and needs of the facility, recommendations were produced to overcome all security concerns and vulnerabilities and to bring the security to the latest technology and best practices.

Roles/Responsibility: Lobo was responsible to perform the security assessment. Lobo was also responsible to produce the security audit report and preparation of the associated security drawings.

One Stone Rd Complex — Guelph, Ontario

One Stone Rd Complex

Budget: $600,000

Project Description: Major security upgrades to the existing multi-storey, multi-tenant, multi-building office complex. Front security desk was also renovated to provide a more aesthetically pleasing, functional and ergonomic monitoring area. The complex also consisted of a large outdoor parking area. Security upgrades included Access Control, Video Surveillance, and Duress Alarm Systems.

Roles/Responsibility: Lobo was responsible to perform a security audit and develop the security requirements for the facilities. Lobo then designed the Security System and was responsible for the development of the security tender documents. Lobo was also involved during the contract admin and commissioning phases.

Archives of Ontario — Toronto, Ontario

Archives of Ontario

Budget: $85,000,000

Project Description: A new state-of-the-art, 130,000 sq ft Archives of Ontario facility at York University’s campus in Toronto. The new, self-contained, academic research facility houses over $400 million in archive collections owned by the Province of Ontario and meets international archival standards. The facility was to welcome public while ensuring the facility and all valuable articles are secured at all times. The facility incorporated various material reference areas accessible to public and secure vaults accessible to designated staff. Each area of the facility had its own very specific unique requirements.

Roles/Responsibility: Lobo developed the Security requirements of the facility. Lobo was also responsible for contract admin services, including construction reviews, resolving construction issues, performance testing and commissioning.

St. Lawrence Market North — Toronto, Ontario

St. Lawrence Market North

Budget: $65,000,000

Project Description: Design and construction of a new 215,000 sq ft, multi-use, multi storey building to replace the existing building part of the iconic St. Lawrence Market. The new building consisted of a market area for vendors, restaurant, Provincial Offences Act courthouse, and multilevel underground public parking area. Due to the multiple uses of the building, an in-depth circulation analysis was performed to ensure the various security levels and requirements for each user group were maintained.

Roles/Responsibility: Lobo developed the Security requirements of the facility. Lobo was responsible for the design of the Security System and IT/Structured Cabling System, including the preparation of system layouts, riser diagrams, door details, and engineering specifications .They were also responsible for contract admin services, including construction reviews, resolving construction issues, performance testing and commissioning.

Canmet – McMaster Innovation Park — Hamilton, Ontario

Canmet – McMaster Innovation Park

Budget: $45,000,000

Project Description: Design and construction of the new 165,000 sq ft Canmet facility part of the McMaster Innovation Park. The facility consisted of various laboratories, research support areas, large storage areas, and administration areas. The laboratories included X-Ray, isotope, magnetic particle, high pressure H20, H2S pressure, etc.

Roles/Responsibility: Lobo developed the Security requirements of the facility in close discussion with Canmet representatives. Lobo was responsible for the design of the Security System, including the preparation of system layouts, riser diagrams, door details, and engineering specifications .They were also responsible for contract admin services, including construction reviews, resolving construction issues, performance testing and commissioning.

Full List of Residential/Commercial Facilities (27)

Full List of Residential/Commercial Facilities

  • 25 Grosvenor, Toronto, Ontario
  • 26 Grenville St – Coroners Office, Toronto, Ontario
  • 77 Grenville St, Toronto, Ontario
  • 77/99 Harbour St Condominium Complex, Toronto, Ontario
  • 145 Cumberland Ave Condominium, Toronto, Ontario
  • 200 Front St, Toronto, Ontario
  • 250 Dundas St, 6th Floor, Toronto, Ontario
  • 300 Water St, Peterborough, Ontario
  • 700 Bay St, Toronto
  • 720 Bay St, Toronto
  • Archives of Ontario, Toronto, Ontario
  • Canmet – McMaster Innovation Park, Hamilton, Ontario
  • CRCHUM, Montreal, Quebec
  • Hillcrest Toronto Transit Commission (TTC)
  • Law Society of Upper Canada, Toronto
  • Lennox and Addington Family and Children Services
  • McMichael Art Gallery, Kleinburg, Ontario
  • One Stone Rd Complex, Guelph
  • Resources Road Complex, Etobicoke
  • Riverdale Probation and Parole Office, Toronto, Ontario
  • Saint John Parking Structure, Saint John, New Brunswick
  • St. Catharines Service Ontario
  • St. Lawrence Market North, Toronto, Ontario
  • St. Michael's Cathedral and Rectory, Toronto, Ontario
  • Stratford Ministry Offices, Stratford
  • Toronto Community Housing - West Don Lands Complex, Toronto, Ontario
  • World on Yonge Condominium Complex, Toronto, Ontario

Standards Standards & Guidelines

Lobo has developed 9 Standards/Guidelines. These include various Ministries, such as the Ministry of Community Safety and Correctional Services (MCSCS), Ministry of Children and Youth Services (MCYS) Ministry of the Attorney General (MAG), Alberta Infrastructure (AI), Shared Services British Columbia (SSBC), and Ontario Provincial Police (OPP). The creation of Standards/Guidelines has allowed Ministries and organizations to standardize their operations, security technology, and security devices utilized throughout their facilities.

Click to view our projects

Ministry of Community Safety and Correctional Services

Ministry of Community Safety and Correctional Services

Electronic Integrated Security System Standards — Ontario

Project Description: Development of the Electronic Integrated Security System Standards for all MCSCS detention centres and jails in Ontario. The Standards detailed the graphical user interface (GUI) and exact sequence of events and operations to control and monitor all alarms. The Standards also detailed the technology, interfaces, and operational requirements for each security system. The integrated security system consists of the following sub-systems: Security Monitoring and Control System, Video Surveillance System, Door Control System, Access Control System, Intercom System, Cell Call System, Public Address System, Passive Duress Alarm System, Active Duress Alarm System, Watchtour System, and Perimeter Security System.

The security standards were to overcome all security vulnerabilities and improve operator control and monitoring efficiency. The Standards will be implemented in all MCSCS correctional facilities in Ontario.

Role/Responsibility: Lobo was the security consultants/prime consultant responsible to develop the Integrated Security System Standards for MCSCS. This included visiting various MCSCS facilities throughout the province and interviewing various operators and management. Lobo worked very closely with MCSCS representatives to develop the MCSCS security operational and functional requirements which was detailed throughout the Standards.

Ministry of Children and Youth Services Guidelines

Ministry of Children and Youth Services Guidelines

MCYS Guidelines — Ontario

Project Description: Development of the Guidelines for MCYS correctional centres in Ontario. The Guidelines detailed the architectural and security requirements for the facilities. The document was to be used as a guide for all new youth correctional facilities in Ontario.

The Integrated Security Sections of the guidelines detailed the technology, interfaces, and operational requirements for each security system. The integrated security system consists of the following sub-systems: Security Monitoring and Control System, Video Surveillance System, Door Control System, Access Control System, Intercom System, Bedroom Call System, Public Address System, Passive Duress Alarm System, Active Duress Alarm System, Watchtour System, Perimeter Security System, Metal Detection System, and X-Ray Detection System.

Role/Responsibility: Lobo was the security consultants responsible to develop the Integrated Security System section of the Guidelines. This included visiting various MCYS facilities throughout the province and developing MCYS security operational and functional requirements.

Generic Output Specifications for AFP Courthouses in Ontario

Generic Output Specifications for AFP Courthouses in Ontario

AFP Courthouses in Ontario

Project Description: Development of the Generic Output Specifications for the Ministry of the Attorney General (MAG). The output specifications were to be used for all new AFP Courthouses in Ontario. The document was to ensure that the requirements for all courthouses are standardized. The output specifications were to incorporate all of MAG’s requirements and the latest security technology suitable in a courthouse application. The output specifications described each system, the associated technology, system functional and performance requirements, and the system interfaces.

The security systems within the output specifications consisted of: Integrated Security, Access Control and Alarm Monitoring, Video Surveillance, Duress Alarm, Parking Alarm, Intrusion Alarm, Audio Surveillance, Door Intercom, Jury Intercom, Detention Door Control, and Distress Alarm Systems.

Roles/Responsibility: Lobo was responsible to develop the Integrated Security System and IT/Voice-Data Structured Cabling System requirements in close discussion with MAG representatives and prepare the associated output specifications.

Alberta Courthouse Standards

Alberta Courthouse Standards

Alberta Standards

Project Description: Development of the new Courthouse Standards for Alberta Infrastructure. The standards were to incorporate the latest security technology suitable in a courthouse application. The security section of the document described each system, the associated technology, system functional and performance requirements, system composition, device locations, system interfaces, and infrastructure. The document was to act as a standard for all new courthouse facilities and existing courthouse facilities in Alberta.

The security systems within the Standards consisted of: Access Control and Alarm Monitoring, Video Surveillance, Duress Alarm, Parking Alarm, Intrusion Alarm, Audio Surveillance, Door Intercom, Jury Intercom, Detention Door Control, Touchscreen Control, Metal Detection, X-Ray Screening, and Optical Portal.

Roles/Responsibility: Lobo was responsible to develop the Integrated Security System requirements in close discussion with Alberta Infrastructure, Courthouse, and Sheriff representatives and prepare the associated Security sections of the Standards.

Ontario Provincial Police (OPP) Accommodations Guidelines for Detachments

Ontario Provincial Police Accommodations Guidelines for Detachments

OPP Guidelines

Project Description: Development and update of the OPP Accommodation Guidelines for Detachments. The document was to be used as a guide for any new and existing OPP detachment throughout Ontario.

The document outlined specific design requirements, device locations, and specific manufacturers and models that are acceptable related to the Security and IT/Voice-Data Systems. The document also provided functional overviews of the systems.

Roles/Responsibilities: Lobo was responsible to develop the Security System and Voice-Data System requirements for the Accommodation Guidelines in close discussion with the OPP.

Full List of Standards & Guidelines (9)

Full List of Standards and Guidelines

  • Alberta Courthouse Standards - Alberta
  • Generic Output Specifications for AFP Courthouses - Ontario
  • Ministry of Children and Youth Services Guidelines - Ontario
  • Ministry of Community Safety and Correctional Services Electronic Integrated Security System Standards - Ontario
  • Ministry of Community Safety and Correctional Services Guidelines - Ontario
  • Ministry of the Attorney General Courthouse Technology Guidelines - Ontario
  • Ontario Provincial Police (OPP) Accommodation Guidelines for Detachments
  • Probation and Parole Guidelines - Ontario
  • Courthouse Technology Guidelines - Ministry of the Attorney General - Ontario
  • Shared Services BC (SSBC) Design Guidelines for BC Courthouse Facilities - British Columbia

Standards Security Audits

Lobo has performed over 25 security audits/assessments. These include various types of facilities including international heritage site, correctional facilities, courthouses, office buildings, condominiums, shopping market, educational and healthcare facilities. These security audits have allowed users to identify security vulnerabilities in the facilities and operations so that solutions can be put forth to overcome all current or potential security vulnerabilities.


Click to view our projects

Atturaif Heritage Site — Saudi Arabia

Atturaif Heritage Site

Project Description: Master Plan for the 27 hectare site, which was the first State in Saudi Arabia. Based on the UNESCO certification, the site was to be transformed into an international tourist attraction consisting of a variety of museums, mosques, souks and historical elements connected through pedestrian catwalks. The site also incorporated a state of the art light and sound show displayed on the existing facade of the buildings. Detailed security assessment was performed, including a threat, risk, and vulnerability assessment, security concepts such as Crime Prevention Through Environmental Design (CPTED), and the development of security zones, security strategy, security systems and security design guidelines.

Roles/Responsibility: Lobo was responsible to perform the security assessment of the site. Lobo was also responsible to produce the security sections of the master plan.

Queen’s Park Complex — Toronto, Ontario

Queen’s Park

Project Description: Detailed security audit of the Queen’s Park complex, including the various buildings. Security audit consisted of a review of all security devices, technology and current security operations. A vulnerability assessment was also included in the report. The security systems included, access control, video surveillance, intercom, intrusion alarms, duress stations and emergency phones.

Roles/Responsibility: Lobo was responsible to perform the security assessment of the complex. Lobo was also responsible to produce the security audit report and associated recommendations.

Glenville and William Davis Courthouse — Brampton, Ontario

Glenville and William Davis Courthouse

Project Description: Detailed security audit/assessment of the 400,000 sq foot courthouse. The security audit included an assessment all the security devices, technology, and review of best practices. The assessment also included a threat, risk, vulnerability assessment. Recommendations were prepared to overcome all the security vulnerabilities.

Roles/Responsibility: Lobo was responsible to perform the security assessment of the courthouse. Lobo was also responsible to produce the security audit report and associated recommendations.

Central North Correctional Centre — Penetanguishene, Ontario

Placeholder

Project Description: Detailed security audit of the 1200 bed maximum security facility including every security system, component, and devices and preparation of a security audit report. The operations and interfaces of every security system were to be analyzed to ensure it meets the requirements of the Ministry of Community Safety and Correctional Services. Security systems included Touchscreen Control, Video Surveillance, Door Control, Intercom, Duress Alarm, Public Address, Watchtour, Intrusion Alarm, Perimeter Security, etc.

Roles/Responsibility: Lobo was responsible to perform the security assessment of the facility, testing every security system and device. Lobo was also responsible to produce the security audit report and associated recommendations.

Saint John City Market — Saint John, New Brunswick

Saint John City Market

Project Description: Detailed security audit of the City Market including every security system, component, and devices and preparation of a security audit report. Audit included a vulnerability assessment and recommendations to overcome any security vulnerability and client concerns. Security systems included Video Surveillance, Door Control, Intrusion Alarm, etc.

Roles/Responsibility: Lobo was responsible to perform the security assessment of the market. Lobo was also responsible to produce the security audit report and associated recommendations.

Full List of Security Audits (25)

Full List of Security Audits

  • 77/99 Harbour St Condominium Complex, Toronto, Ontario
  • 145 Cumberland Ave Condominium, Toronto, Ontario
  • 330 University Ave Courthouse, Toronto, Ontario
  • 361 University Ave (Toronto) Courthouse, Toronto, Ontario
  • 393 University Ave Courthouse, Toronto, Ontario
  • Atturaif Heritage Site, Saudi Arabia
  • Barrie Courthouse, Barrie, Ontario
  • Brookside Youth Detention Centre, Cobourg, Ontario
  • Centennial College, Scarborough, Ontario
  • Central East Correctional Centre, Lindsay, Ontario
  • Central North Correctional Centre, Penetanguishene, Ontario
  • Elgin Middlesex Detention Centre, London, Ontario
  • Grenville and William Davis Courthouse, Brampton, Ontario
  • Hamilton Wentworth Detention Centre, Hamilton, Ontario
  • Happy Rolph’s Petting Farm, St. Catharines, Ontario
  • John Sopinka Courthouse, Hamilton, Ontario
  • Osgoode Hall, Toronto, Ontario
  • Ottawa Carleton Detention Centre, Ottawa, Ontario
  • Princess Margaret Hospital – Cancer Care Ontario, Toronto, Ontario
  • Queen’s Park, Toronto, Ontario
  • Saint John City Market, Saint John, New Brunswick
  • St. Catharines Courthouse, St. Catharines, Ontario
  • Wellington County Courthouse, Guelph, Ontario
  • Windsor Courthouses, Windsor, Ontario
  • Windsor Jail, Windsor, Ontario

Services

Security


Lobo Consulting Services Inc. (Lobo) specializes in providing engineering design solutions for Integrated Security Systems. Our renowned expertise allows us to provide clients with innovative solutions, utilizing state of the art technology that is best suited for the clients' requirements.

Lobo is comprised of independent security consultants with no affiliation to any manufacturer or contractor. As such, Lobo can provide security solutions best suited for each client.

Our expertise has allowed us to provide clients with a wide range of security services beginning with the initial development of security requirements through to the commissioning and testing of a security system in its final stages.

Specifically, our services include:

Security Assessments / Audits / Studies & Masterplans


Lobo provides full security system assessments looking at the current operations and security systems to determine if they meet the needs of the facility. Lobo analyzes the function and life cycle of existing security technology and equipment. Through meetings with user groups, Lobo uncovers and outlines all security concerns and potential vulnerabilities.

Lobo also provides in-depth Threat-Risk-Vulnerability assessments for new and existing facilities.

Using the information obtained during the assessment phases and design principles such as Crime Prevention Through Environmental Design (CPTED), Lobo produces recommendations to overcome the current vulnerabilities and options to meet the needs of the facility.

Lobo prepares reports outlining all existing conditions, detailed recommendations and budget estimates associated with the recommendations.

Design


Lobo provides full engineering design services for the following systems: Touchscreen Control, Video Surveillance, Video Analytic, Access Control, Detention Door Control, Intercom, Public Address, Audio Surveillance, Duress Alarm, Personal Duress Alarm, Watchtour, Cell Call, Video Visitation, Perimeter Security, Fence Detection, Intrusion Detection, X-Ray Screening, and Metal Detection.

Security system design should be dictated by the specific operational and functional requirements of each facility rather than having the design determine how the institution operates. To ensure this, Lobo meets with the site representatives to fully understand the operational and security requirements of the institution. Based on these requirements, Lobo provides innovative design solutions best suited to meet the needs of the facility.

Lobo prepares engineering specifications and AutoCAD drawings, including:
  • system layouts to indicate the location of all security devices
  • system riser diagrams to indicate the system interconnections
  • door details to indicate the door devices and door operations
  • sketches and details

Lobo coordinates security designs with other disciplines such as architectural, mechanical and electrical engineering.

The benefits of Lobo's designs include:
  • in-depth system integration
  • latest technology
  • creative solutions best suited for the users
  • extensive experience from a wide variety of facility types

These benefits provide system and alarm monitoring efficiency that minimizes response time to security related incidents.

Contract Administration / Commissioning


Lobo provides full contract administration services. This includes issuing site instructions and change notices, and resolving construction related issues.

Lobo reviews shop drawings to ensure the products supplied meet the requirements of the design.

Lobo attends site meetings during construction. Lobo also performs site reviews and inspections related to security systems and prepare the related inspection reports.

Lobo performs full commissioning of the security systems, providing installation inspection of each security device and system. Lobo tests the performance of each device. Lobo also ensures that all interfaces between systems and devices are provided as per the contract documents and the design. Lobo's detailed commissioning provides our clients assurance that the security systems installed meet the requirements of the design documents and operational requirements of the users.

Standards & Guidelines


Lobo develops Security Standards and Guidelines for Government Ministries and organizations. These security standards allow organizations to standardize their security systems and security requirements. This ensures that the organization is utilizing the same requirements to ensure consistency is provided across all the facilities.

Security standards not only aid management, but also aid security personnel moving from one facility to another. This standardization minimizes the time involved in retraining and learning security systems and procedures.

To develop the Security Standards/Guidelines, Lobo first develops a strong understanding of the operational requirements of the facility. Lobo meets with site representatives to develop the security requirements in detail. Through interviews with designated site representatives, Lobo determines what security measures have worked well in the past compared to those that have not proven effective. This helps direct the security concepts incorporated in the Standards/Guidelines.

The Security Standards can include descriptions of every system and the specific requirements related to each system. Performance requirements of every security device can also be provided, including the technology to ensure comparable products are purchased at each related site. Exact manufacturers and models for security systems and devices can be incorporated as required. Specific operational requirements and interfaces for systems can be detailed. The level of detail of the Standards/Guidelines is determined by the client’s requirements.

IT / Voice - Data Structured Cabling


Lobo Consulting Services Inc. (Lobo) provides engineering design solutions for IT / Structured Cabling Systems.

Specifically, our services include:

Design


Lobo provides full engineering design services for IT/Structured Cabling Systems. This includes voice and data outlets, horizontal cabling, backbone cabling (fibre and copper), patch panels, BIX blocks, racks, rack cabinets, cable management, etc.

Lobo meets with the site representatives to fully understand the operational and IT requirements of the facility. Based on these requirements, Lobo provides design solutions that are best suited to meet the IT needs of the facility.

Lobo prepares engineering specifications and AutoCAD drawings, including system layouts to indicate the location of all voice-data outlets, system riser diagrams to indicate the system interconnections, IT room layouts, sketches, etc. Lobo coordinates IT/Structured Cabling designs with other disciplines such as architectural, mechanical and electrical.

The benefits of Lobo's designs include: in-depth system integration, latest technology, creative solutions best suited for the users, and extensive experience from a wide variety of facility types. The above provides system and alarm monitoring efficiency that minimizes response time to security related incidents.

Contract Administration / Commissioning


Lobo provides full contract administration services. This includes issuing site instructions and change notices, and resolving construction related issues.

Lobo reviews shop drawings to ensure the products supplied meet the requirements of the design.

Lobo attends site meetings during construction. Lobo also performs site reviews and inspections related to IT/Structured Cabling systems and prepare the related inspection reports.

Lobo performs full commissioning of the IT/Structured Cabling systems, providing installation inspection of each voice-data outlet, rack, and associated patch panels and BIX. Lobo reviews the test results of each cable segment. Lobo ensures that all elements are provided as per the contract documents and the design. Lobo's detailed commissioning provides our clients assurance that the IT/Structured Cabling systems installed meet the requirements of the design documents and operational requirements of the users.


Company

Who We are


Established in 1997, Lobo Consulting Services Inc (Lobo) is a privately owned corporation comprised of a dedicated group of consultants, engineers, and designers who work together to deliver innovative solutions for Security and IT/Structured Cabling Systems.

We specialize in security design for maximum security justice facilities such as correctional, courthouse and police facilities. We also provide our services to a variety of both private and government institutions including healthcare and educational facilities, office buildings, museums and condominiums.

What Makes Us Different


We are independent consultants that have no affiliation with any manufacturer or contractor. This enables us to provide unbiased, cutting edge designs and recommendations to our clients.

Each one of our team members have a current and comprehensive understanding of security systems and design, allowing Lobo to incorporate the latest technology into our superior designs. Our team based approach allows members of our group to collaborate ideas, enabling us to optimize security features and deliver the highest quality designs to our clients.

We have provided service to a wide range of facilities with varying levels of security, enabling our team to contribute experience and expertise acquired from past projects.

We understand that in order for security measures to be effective in a facility, they must align with the functional procedures carried out within the institution. With this in mind, we believe that security system design should be dictated by the specific operational and functional requirements of each facility rather than having the design determine how the institution operates. This ensures that the design solution is best suited for the operations of our clients. .

Our Values


Integrity Without Compromise.
We believe in showing our team members, colleagues and clients the utmost respect. Therefore, honesty and transparency is essential to our everyday practices. This ensures that all parties are treated fairly fostering strong, trusting relationships.

Our people are our most valuable asset.
We feel that a company’s success is defined by the sum of the strengths of each individual member in its team. At Lobo we recognize the importance of challenging our team members to help them reach their highest potential. We invest in our people by providing access to training, workshops and conferences. This translates into a motivated, forward thinking team.

Our clients define our practices.
We strive to meet each and every one of our clients’ needs. We achieve this by regularly adapting our practices to provide consistently efficient, high quality services to meet the most rigorous client expectations. This results in satisfied clients who seek our services repeatedly.

Innovation is our competitive advantage.
We believe in staying up to date with constantly evolving technologies allowing us to provide creative, cutting edge solutions. We are dedicated to constantly improving our designs and challenging our way of thinking. In an ever changing industry, we strive to implement the latest technologic advances to remain at the forefront.

Our Vision


At Lobo Consulting Services our vision is to be recognized as a leader in engineering design solutions for Integrated Security Systems and IT/Structured Cabling Systems. Having serviced many facilities within Canada, we are moving towards becoming national leaders in our field and are taking steps to expand our services globally.

We strive to remain at the front line of security and IT design by incorporating the latest technological advancements in our field. This enables us to constantly challenge standard design practices leading to the development of creative and innovative solutions.

We are committed to continue satisfying our client’s needs through high quality, customized consulting services, and to meet unique requirements with a design review process that ensures the final product meets the most rigorous client expectations. We measure our success by the client’s complete satisfaction which is reflected in the high number of return clients.


Contact

Lobo Consulting Services Inc.
Security & IT Comm. Systems Consultants

5995 Avebury Rd, Suite 902, Mississauga, Ontario, Canada, L5R 3P9
Tel: (905) 502-1234   •   Fax: (905) 502-1244   •   ContactUs@LoboCSinc.com



www.LoboCSinc.com
